Weight: 1.2 lb
Small three-phase motors on pumps, fans and conveyors need overload protection matched to a low full-load current. The Techspan TR2D09307 is a 3-pole bimetallic thermal overload relay with a 1.6 to 2.5 A setting range, trip class 10 and 1NO+1NC auxiliary contacts. It mounts directly under Techspan T-line TC1-D contactors to build a compact starter.
| Spec | Detail |
|---|---|
| Brand | Techspan (T-line) |
| Model | TR2D09307 |
| Type | 3-pole bimetallic thermal overload relay |
| Setting range | 1.6-2.5 A |
| Trip class | 10 |
| Auxiliary contacts | 1NO + 1NC |
| Rated operating voltage (UL/CSA) | 600 V |
| Motor ratings (AC-3, 3-phase) | 0.37 kW at 220 V; 0.75 kW at 380 V; 1.1 kW at 415/440 V; 1.5 kW at 660 V |
| Compatible contactors | TC1-D09, TC1-D12, TC1-D18 (direct mount) |
| Approvals | UL, CSA, IEC 60947-4-1 |
Pro tip from the counter
This relay's terminals line up only with Techspan T-line TC1-D09, D12 and D18 contactors. If you're replacing an overload on a starter built with another brand's contactor, check the pole spacing and mounting first, because a close-looking IEC relay from a different maker may not bolt under it.
Best for: small pump and fan motor starters, conveyor and packaging machine panels, OEM control panels, replacing tripped or failed overloads
Downloads: T&F-Line contactors and overloads catalogue (PDF)
Shipped across Canada from Vaughan, ON. Panel shops can get trade pricing through a quote or by calling (905) 553-7171.
| Feature |
Thermal Overload Relay, 1.6 - 2.5A, 3 Pole
