Weight: 1.2 lb

Large Teck90 feeders into switchgear, MCCs and pull boxes need a fitting that seals the jacket and bonds the armour in one step. The Techspan RTK-150-12 is a 1-1/2 in Remke PowR-Teck aluminum Teck cable connector for cable measuring 1.850 to 1.975 in over the jacket. It is a one-piece, NEMA 4 and IP65 rated design that goes on without taking the fitting apart.

Why industrial electricians pick it

  • One-piece connector installs without disassembly on heavy cable.
  • Grounding seal bonds the armour for ground continuity.
  • Neoprene bushing for pull-out strength plus an embedded Viton O-ring.
  • NEMA 4 / IP65 for wet and wash-down locations.
  • CSA certified for Canada and the US, file 28985.

Specifications

Spec Detail
Brand Techspan (Remke PowR-Teck)
Model RTK-150-12
Hub size 1-1/2 in NPT
Cable range over jacket 1.850-1.975 in
Cable range over armour 1.740-1.895 in
Exposed armour length 1-1/2 in
Material Aluminum
Sealing Neoprene bushing, embedded Viton O-ring
Rating NEMA 4, IP65
Approval CSA (Canada and US), file 28985

Pro tip from the counter

The connector's NEMA 4 seal ends at the enclosure wall. On a knockout rather than a threaded hub, use a sealing locknut or a sealing ring between the connector and the box, and snug the locknut firmly so a heavy feeder can't rock the fitting loose and open a leak path into the gear.

Best for: Teck90 feeders into switchgear and MCCs, industrial and mining sites, wash-down and outdoor enclosures, large pull and junction boxes
