Weight: 0.27 lb
Switchboards and generator panels often have a single analog voltmeter that needs to read all three phase-to-phase voltages. The Lovato GX1667U is a front-mount rotary cam voltmeter switch (scheme 67) with two contact wafers that selects L1-L2, L2-L3 and L3-L1. Panel builders fit it beside the meter on a 48 x 48 mm plate for a clean, compact door layout.
| Spec | Detail |
|---|---|
| Brand | Lovato Electric |
| Model | GX1667U |
| Function | Voltmeter switch, phase-phase L1-L2 / L2-L3 / L3-L1 (scheme 67) |
| Contact blocks | 2 wafers |
| Current rating | 16 A Ith (IEC); 12 A thermal (UL/CSA) |
| Insulation voltage | 690 V IEC / 600 V UL/CSA |
| Rated operational voltage | 440 VAC |
| Mounting | Front mount, 48 x 48 mm plate |
| Protection | IP65 front, IP20 terminals |
| Terminals | Screw, 0.5 Nm max |
| Listing | cULus, EAC |
Pro tip from the counter
Check the system voltage before specifying it: Lovato lists a 440 VAC rated operational voltage, so on 575/600 V Canadian services have the panel designer confirm suitability with Lovato or measure through potential transformers. Fuse the voltage taps ahead of the switch so a wiring fault in the door does not trip the main.
Best for: switchboard and distribution panel metering, generator control panels, industrial control panel builders, 3-phase voltage checks
Ships across Canada from Vaughan, ON. Panel shops can get trade pricing through a quote or at (905) 553-7171.
| Feature |
CAM VOLTMETER 16A FRONT MOUNT L1L2-L2L3-L3L1
$63.05
Current
|
|---|---|
| Brand | Lovato |
| Type | |
| Availability | In stock |
| Rating | No reviews |
Our counter is at 8520 Jane St, Unit 5, Vaughan, ON L4K 5A9, open Monday to Friday, 8am to 4pm. Order online and collect, or bring a material list and we will price it at the counter. Contractors and DIY customers are both welcome.
