The Arlington CPS50 is a non-metallic sleeve you fasten to the form before the pour. It leaves a 5 in hole in the concrete, and Arlington lists it for 4 in pipe, so cable or conduit can run from one floor to the next.
The 5 in is the hole, not the conduit size. Conduit measures wider than its trade size. 4 in rigid PVC is 4.5 in across, which leaves about 1/4 in all round in this sleeve. 5 in conduit is 5.563 in across and won't fit, so use the CPS60.
| Spec | Detail |
|---|---|
| Brand | Arlington Industries |
| Model | CPS50 |
| Hole size | 5 in |
| Pipe size | 4 in |
| Height | 8.5 in |
| Width | 5.125 in |
| Flange | 6.625 in |
| Material / colour | Non-metallic, black |
| Weight | 0.430 lb each |
| Made in | USA |
| Manufacturer packaging | Carton of 10 |
| Model | Hole in the concrete | Takes pipe |
|---|---|---|
| CPS15 | 1-1/2 in | 1 in |
| CPS20 | 2 in | 1-1/2 in |
| CPS30 | 3 in | 2 in |
| CPS40 | 4 in | 3 in |
| CPS50 | 5 in | 4 in |
| CPS60 | 6 in | 5 in |
Arlington's steps: nail or screw the sleeve to the form, cut it off flush after the concrete sets, then insert the conduit. Sleeves stack up to 23 in for a thicker pour.
Before you pour: Arlington's sheet doesn't state a UL or CSA listing, or a fire, water, gas or radon rating. If the sleeve goes through a fire-rated floor or a foundation, ask your inspector or firestop designer first.
