LED Wall Packs

LED Wall Packs

Rugged LED wall packs for building exteriors, entries and security, with dusk-to-dawn options.

14 Produits

Related categories

Buying for a project or in volume?

Contractors and bulk buyers can get project pricing. Send your material list and we will quote it back, priced in CAD, shipped Canada-wide or ready at our Vaughan counter.

Apply for Contractor Pricing → Request a Project Quote →
Full guide Wall Pack & Area Lighting Guide →
About this category

LED wall packs for Canadian building exteriors, parking areas, and loading doors, covering 14 commercial-grade units from EiKO, Reno Lighting, and Fotonz. Voltage options go from standard 120-277V through 347-480V for Canadian commercial services.

  • EiKO 15W cube wall pack with photocell from $85, DLC Premium certified
  • Reno multi-CCT wall packs, 30/40/50W selectable, 120-347V, from $129
  • Slim adjustable-angle packs at 21/28/35W for shallow mounting
  • EiKO glass wall packs from 30W to 120W with 0-10V dimming, up to 13,000 lumens
  • Fotonz 40W and 90W packs in 4000K from $90

Commercial orders routinely clear the $150 free shipping threshold for Ontario and Quebec, and the rest of Canada receives 10% off at checkout. We match prices, hand product over the counter in Vaughan, ON, and ship nationally in 3 to 7 business days.

Wall packs are exterior LED fixtures mounted on a building wall to light parking areas, loading doors, and walkways. Two specs decide the order: voltage and lumen output. Canadian commercial services frequently run 347V, so check whether the site needs a 120-277V or a 347-480V driver before buying, because drivers are not field convertible. Many units here are multi-CCT and multi-wattage selectable, so one part number covers several sites. Photocell models switch at dusk with no control circuit, while 0-10V dimming needs a control pair run to the fixture.
Common questions
What voltage wall pack do I need?
Match the fixture to the building service. Most light commercial work is 120-277V. Larger Canadian commercial and industrial services commonly run 347V, which calls for a 347-480V rated unit such as the EiKO glass wall packs here. Confirm the voltage at the panel with your electrician first, since the driver cannot be changed in the field.
How many lumens do I need over a loading door?
A single man door or service door is usually covered by 2000 to 3000 lumens, matching the 15W and 30W cube packs. A loading bay or a stretch of parking lot wants 5000 lumens and up, into the 50W to 120W glass packs. Mounting height and throw distance both shift that number.
What does DLC listed mean?
DLC is the DesignLights Consortium, which tests and lists commercial LED products for efficiency. Many Canadian utility rebate programs require a DLC listed fixture to qualify. Several packs here state DLC Premium or DLC V4.0 on the product page. Check your utility current program rules before counting on a rebate.
Should I use a photocell or switch the fixtures from inside?
Either approach works. A built-in photocell turns the fixture on at dusk and off at dawn with no extra wiring, which suits sites without a control circuit. If a lighting contactor or time clock already exists, a unit without a photocell is simpler. Avoid putting photocell fixtures on a timer controlled circuit.
Do commercial wall pack orders qualify for free shipping?
Orders over $150 ship free to Ontario and Quebec addresses, which most multi-fixture orders clear. The rest of Canada receives 10% off applied at checkout. Shipping runs about 3 to 7 business days nationally, and pickup is available at our counter at 8520 Jane St, Vaughan, ON. We price match.
